Display (Avidyne Atlas)

• 5.7” Diagonal w/Touch Screen
• Full VGA – 640 x 480 pixels
• 65,535 colors
• Ultrabright sunlight readable w/LED Backlighting

Dimensions (Avidyne Atlas)

• Width: 5.750” (190.50mm)
• Height: 7.500“ (146.05mm)
• Depth: 11.900“(302.26) behind panel including connectors

Weight (including tray and connectors)

• 8.50 lbs (3.855 kgs)

Power Requirements

• 11 – 33VDC
• 2.2A/4.0A XMIT @ 28vdc

VHF & VOR/LOC

• 16-watt transmitter (Class 3, 5)
• Simultaneous reception of two channels, voice or data
• 8.33KHZ or 25KHZ operation (Class C, E)
• VOR-RTCA DO-196
• LOC-RTCA DO-1965
• UHF GS-RTCA DO-192

GPS

• 16-Channel GPS/SBAS Receivers
• RTCA DO-178B and DO-254 Level B
• RTCA DO-160E
• Meets DO229D, Beta Class 3
• Accuracy:
• – Autonomous Position: 3 meters (CEP 50%), 5 meters (95%)
• – SBAS Differential Position: 1 meter (CEP), 3 meters (95%)
• – Velocity Sccuracy 0.1 knots (95%)
• Dynamics:
• – Acceleration: 10g max
• – Speed: 1,000 knots
• – Altitude: 50,000 ft

Environmental

• DO 160E
• To 50,000 Ft
• -20C to +55C Operating
• +70C Short Term
