Description
Physical
Unit dimensions, WxHxD: 4.9″ x 1.3″ x 3.4″ (12.44 x 3.30 x 8.64 cm)
Weight: 0.75 lbs (0.34 kg)
Anti-slip mat (bottom of unit only)
Performance
Operating temperature: -20°C to +60°C (-4°F to 140°F)
Operating altitude: To 55,000 ft
Nominal operating velocity range: 0 – 800 kts (411 m/s)
Power input: 10 to 32 VDC, 3.5 W max.
Battery type: Lithium-ion rechargeable (built-in)
Charge temperature: Unit may not charge at extreme temperatures below 0° C (32° F) or above 32° C (90° F)
Typical battery operating time: 8 hours
Connections
18-pin power and data connector
microUSB
ADS-B MCX antenna port
GPS MCX antenna port
Wireless Connext™ (Bluetooth®)
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
