$3,395.00
REPLACE ANALOG GAUGES WITH ELECTRONIC DISPLAYS- Adaptable to a full range of instrument formats and functions, our GI 275 electronic display lets you keep the classic look of your panel while upgrading with modern, reliable glass touchscreen display technology.
Out with the old, in with the new. It flush mounts in a standard 3-1/8” round cutout.
From piston singles to jets, it’s STC’d for more than one thousand make/model aircraft.
How do you see it? Attitude, altitude, airspeed, CDI, HSI, MFD or EIS.
It’s available with precise digital ADAHRS and interface to drive select autopilots.
Connect your cockpit with built-in Wi-Fi® connectivity and BLUETOOTH® technology.
Know you’ll get home with up to 60 minutes of optional backup battery power.
Part Number: 010-02325-00
Lead times may vary.
Width: 3.25″ (82.6 mm)
Height: 3.25″ (82.6 mm)
Depth: 6.44″ (163.6 mm)
Depth with Connector: 7.40″ (188.0 mm)
Unit Weight: 1.9 lbs (0.86 kg) to 2.4 lbs (1.1 kg)
Active Display Size: 2.69” diameter
Display Resolution: 480 x 433 pixels
Operating Voltage: 14/28 VDC
Operating Temperature Range: -20°C to +55°C
Altitude Range: -1,500 ft to 55,000 ft
Wi-Fi Class: 802.11b/g/n
| Weight | 2.4 lbs |
|---|
